Agro Chem is a Raven Platinum Partner, Ag Leader Blue Delta dealer, and dealers for Capstan Ag and Micro-Trak products. We offer a wide variety of products including autosteer systems, liquid and granular application controls, yield monitoring, planter control and monitoring, and water management controls. Through years of experience our three Wabash Precision Ag Specialist or our one Ohio Precision Ag Specialist can assist in helping solve your precision needs then install and show you how to operate the system.
Two options for axle width: a standard version slides from 80” to 120” and the wide version from 112” to 152” (with 46” tires only)
The low tire pressure of a radial dramatically increases the size of the footprint on the ground.
The wings are constructed with lightweight but durable composite materials. Couple that with full hydraulic accumulator suspension to get unprecedented ride. You won’t find all the springs, shocks, and cables found on many competitive booms.
Hydraulic 1 1/2" x 1 1/4" (60') or Hydraulic 2" x 1 1/2" (80')
Tires: 320/90R46 Radial or 14.9R46 Radial
Tractor Requirements: 165 HP, Enclosed Cab
Transport Height: 10'
Transport Width: 12'
1600- or 1850-Gallon Tank
Full Length Formed Steel Tank Support
Hydraulic Centrifugal: 2" x 1 1/2"
Tires: 380/90R46 Radial or 18.4R46 Radial
Comes standard with an adjustable axle, a wide axle option is available on the 1200 gal. model
A true 90’ boom that features a dual breakaway system — one on the inner wing and one on the outer wing. The inner breakaway will reset automatically while the outer breakaway can be reset hydraulically from the cab.
It's the big brother of the 6000 series liquid applicator. With the toolbar mounted to the front, the applicator has great visibility and control. It is built to stand up to the extra-rugged conditions found in today's minimum tillage practices.
Great row visibility and applicator control
32 1/2" of ground clearance on the main frame
Double bar center section of 4" x 6" heavy wall tubing
11' center section with toolbar lengths up to 35'
Adjustable wheel track 64" to 120"
Heavy duty 8 on 8 hubs
750-gallon fully drainable leg tank
1000-gallon tank is optional
Hydraulic folding wings and hydraulic lift
4" x 4" pole jack swivels out of the way
Double bar tubular steel pole
16.5 x 16.1 implement tires
Adjustable tractor clevis
Single or twin piston pumps
AG 37 Coulter assemblies
AG Systems 7200 Toolbar The AG Systems Nitromaster Pull Type Toolbars are designed for today's modern farmer. Built to be pulled by the largest 4 x 4 tractors, these extra-rugged applicators will stand up where others have failed.
The main frame is formed from 4" x 6" Tubular steel with 1/2" walls. Designed to carry a heavy load of disc covers, rolling coulters and spring bundles, even at 15" spacings the Nitromaster Toolbar will maintain the balance needed for smooth, easy pulling.
Pre-plant NH3 Application
Side-Dress NH3 Application
Strip-till or Zone Banding
Heavy-duty 4" x 6" x 1/2" wall tubing will stand up where others have failed
Designed to carry the heavy loads of coulters, spring bundles, and disc covers
Built to adapt to most all row spacing
Adjustable walking tandem axles
Master/Slave designed hydraulic lift system provides a uniform lift
AG Systems Brute II Bumper
Brute II is available in chrome or white
Takes the strain out of heavy loads
Features a two-way drawbar that swings side to side 15" and extends 6" for easy hook-up
Double safety lock
2 massive coil springs
Designed in the wraparound style
AG Systems Nurse Tank Trailer
Available as 1,000 gallon or 1,625 gallon
2 x 6 tube
14,000 lbs./18,000 lbs. G.V.W.R.
7,000#/9,000# Dexter EZ lube axle with slipper spring
